Guide to the LaunchPad MSP430FR5994 (MSP-EXP430FR5994)

The MSP-EXP430FR5994 features 256KB of FRAM (Ferroelectric Random Access Memory), and 8 KB of SRAM, plus a micro-SD-card slot.

This hardware is open source! Get the MSP-EXP430FR5994 Software Examples and Design Files.

Installing the drivers

If you have not already done so, follow the instructions for your operating system to install the drivers here:

Pin Map

The following diagram shows the complete pin map for the MSP430FR5969 LaunchPad in Energia. Click the image to enlarge.
